Brass TerminalRing Series
Ring Series Terminal - LA103 Medium Hole (SWT001003M)
Part #: SWT001003M
LA103 ring terminal with medium hole (3.70mm ID) for 1.50-2.20 sq mm cable. High conductivity brass construction.
Specifications
OD Ø7.00 mm
ID Ø3.70 mm
Cable Size SQ. MM1.50-2.20
DescriptionLA103 Medium Hole
MaterialCuZn-63/37
Standard PackingSpool-8000 Cut-1000
Applications:
AutomotiveElectrical Connections
